Duplex Drop Cable

Mikrolink Fiber

Mikrolink Fiber


Geometrical Characteristics
Duplex Cable Type     φ3.0   φ2.0   φ1.8   φ1.6
Duplex Cable Diameter(mm)   2.85/5.80 1.95/4.00 1.80/3.70 1.75/3.60
Duplex Cable Weight(kg/km)   14   8   7.8   7.6
TBF Diameter(μm)     900±50       600±50

Fiber
Fiber Type(core/cladding dimension)   8.3/125, 50/125, 62.5/125

Environmental Characteristics
Storage Operating Temperature   -40ºC ~+70ºC

Mechanical Characteristics
Max Load(N)       Long Term 100 100 100 50
        Short Term 200 200 200 100
Bending Radius(CM)     Dynamic 20×H (H: Cable Axis)
        Static 10×H (H: Cable Axis)
Transmission Characteristics
        SMF   50/125,10g5/125 62.5/125
        1310/1550(nm) 850/1300(nm)   850/1300(nm)
Max Attenuation(dB/km)     0.45/0.30 3.5/1.5     3.5/1.5
AVG. Attenuation(dB/km)     0.40/0.25 3.0/1.0     3.0/1.0
Min Bandwidth(MHz·km)     --------   400/400     160/500

Drop Cable diameter varies between 2 mm and 3 mm, can be produced according to the desired feature.

Drop Cable can be produced in desired colors.

Drop Cable is LSZH.
