LC/APC-LC/APC | 12 Fibers Universal Fanout | Single Mode G657.A2 | 4.8/1.8mm

MLU12FUFLA-SM-4.8mm

Home Page Other Products Other LC/APC-LC/APC | 12 Fibers Universal Fanout | Single Mode G657.A2 | 4.8/1.8mm

LC/APC-LC/APC | 12 Fibers Universal Fanout | Single Mode G657.A2 | 4.8/1.8mm


This universal (indoor/outdoor) fanout assembly has 12 green LC/APC connectors on both sides, and they are connected by12single-mode A2 1.8mmfiber cords that have 12 fibers with 9µm core diameter and 125µm cladding diameter, and they are bonded within a 4.8mm main cord.LC means "Lucent Connector" and it has 1.25mm diameter ceramic ferrule.The connector ferrule on one side isAPC, which means it is polished in an 8°angle for a high precision angled physical contact.

Specifications

  • Insertion Loss (IEC 61300-3-4-Method-B): ≤ 0.30 dB
  • Return Loss (IEC 61300-3-6-Method-B): ≥ 50 dB (UPC),60 dB (APC)
  • Durability: ≥ 1000 mating cycles
  • Flammability: UL94 V-0
  • Operating Temperature: -40?C to +85?C
  • Connector End Face Geometry: IEC 61755-3
  • LC Connector Compliance: IEC 61754-20, TIA 604-10-A, RoHS
  • SC Connector Compliance: IEC 61754-4, TIA 604-3, RoHS
  • FC Connector Compliance: IEC 61754?13, TIA 604?4?A, RoHS
  • ST Connector Compliance: IEC 61754?2, TIA 604?2, RoHS
  • E2000 Connector Compliance: IEC 61754 - 15, TIA 604 - 16, RoHS
